IP090160C I-SERIES_Plus_C Model Series
Select a thumbnail to view a larger version
I-SERIES Plus™ line of Combi Condensing Gas Boilers offers unmatched value and performance with an expanded product line that features Smart Sense ™ Adaptive Gas Valve technology. Combi Boiler CH 90k / DHW 160k, NG
- Warranty 12 yrs / 5 yrs / 1 yrs
- 15000 BTU / (4.39 kW) (minimum)
160,000 BTU / (46.9 kW) (maximum)
- Indoor
Specifications
Product Depth | 11.5 in / (292.1 mm) |
---|---|
Product Height | 26.4 inch / (670.56 mm) |
Product Width | 18.5 inch / (470 mm) |
Product Weight | 66 lb / (29.9 kg) |
Gas Type | NG or LP |
Installation Type | Indoor |
Recirculation Capable | Yes |
Residential ENERGY STAR® | Yes |
Domestic Hot Water Flow Rate (Maximum) | 7.9GPM |
Wi-Fi Capable | Yes |
SCAQMD Approved | Ultra Low NOx |
Documentation
-
I Series Plus 150K BTU and Smaller Combi Boiler Owners Installation and Operation Manual EnglishPDF10 MB150K BTU and Smaller Boiler User Owners Installation and Operation Manual - I Series Plus ModelsPDF3 MB150K BTU and Smaller Boiler Owners Installation and Operational Manual French - I Series Plus ModelsPDF3 MB
-
Warrantyi
Warranty - Standard for Residential | 12 yrs / 5 yrs / 1 yrs |
---|---|
Warranty - Standard for Commercial | 5 yrs / 5 yrs / 1 yrs |
iWarranty information is available in the Installation & Owner Manual.
